Placa-Mãe Asus H610M-D D4, Intel, mATX, DDR4, RGB - 90MB1A00-M0EAY0

Características:

- Marca: Asus

- Modelo: H610m-d

Especificações:

- cpu intel® socket lga1700 for 12th gen intel® core™, pentium® gold and celeron® processors*

- supports intel® turbo boost technology 2.0 and intel® turbo boost max technology 3.0**

- ** intel® turbo boost max technology 3.0

- support depends on the cpu types. chipset intel® h610 chipset memória 2 x dimm, max. 64gb, ddr4 3200/3000/2933/2800/2666/2400/2133 non-ecc, un-buffered memory* dual channel memory architecture

- supports intel® extreme memory profile (xmp)

- * actual memory data rate depends on the cpu types and dram modules, for more information refer to www.asus.com for memory support list. gráficos 1 x d-sub port 1 x hdmi® port**

- * graphics specifications may vary between cpu types. please refer to www.intel.com for any updates.

- ** supports 4k60hz as specified in hdmi 2.1. slots de expansão intel® 12th gen processors 1 x pcie 4.0 x16 slot intel® h610 chipset 1 x pcie 3.0 x1 slot armazenamento total supports 1 x m.2 slot and 4 x sata 6gb/s ports intel® h610 chipset m.2 slot (key m), type 2242/2260/2280 (supports pcie 3.0 x4 & sata modes) 4 x sata 6gb/s ports * the m.2 slot shares bandwidth with the sata6g_4 port. when a device in sata mode is installed on the m.2 slot, the sata6g_4 port cannot be used. rede 1 x realtek 1gb ethernet usb rear usb (total 6 ports) 2 x usb 3.2 gen 1 ports (2 x type-a) 4 x usb 2.0 ports (4 x type-a) front usb (total 4 ports) 1 x usb 3.2 gen 1 header supports additional 2 usb 3.2 gen 1 ports 1 x usb 2.0 header supports additional 2 usb 2.0 ports áudio realtek 7.1 surround sound high definition audio codec*

- supports: jack-detection, multi-streaming, front panel jack-retasking

- supports up to 24-bit/192 khz playback audio features

- audio shielding - premium audio capacitors

- dedicated audio pcb layers

- * a chassis with an hd audio module in the front panel is required to support 7.1 surround sound audio output. portas i/o no painel traseiro 2 x usb 3.2 gen 1 ports (2 x type-a) 4 x usb 2.0 ports (4 x type-a) 1 x d-sub port 1 x hdmi® port 1 x realtek 1gb ethernet port 3 x audio jacks 1 x com port 1 x ps/2 keyboard/mouse combo port painel interno fan and cooling related 1 x 4-pin cpu fan header 1 x 4-pin chassis fan header power related 1 x 24-pin

- main power connector 1 x 8-pin +12v

- power connector storage related 1 x m.2 slot (key m) 4 x sata 6gb/s

- ports usb 1 x usb 3.2 gen 1

- header supports additional 2 usb 3.2 gen 1 ports 1 x usb 2.0 header

- supports additional 2 usb 2.0 ports

miscellaneous

- 1 x rgb header

- 1 x clear cmos header

- 1x front panel audio header (aafp)

- 1 x lpt header

- 1 x s/pdif out header

- 1 x speaker header

- 1 x spi tpm header (14-1pin)

- 1 x 10-1 pin system panel header recursos especiais asus

- 5x protection iii

- digi+ vrm

- languard

- overvoltage protection

- safeslot core

- stainless-steel back i/o asus q-design

- q-dimm

- q-slot asus thermal solution

- aluminum heatsink design asus lighting control

- rgb header recursos de software asus exclusive software armoury crate ai suite 3

- performance and power saving utility turbov evo epu digi+ vrm fan xpert asus cpu-z norton anti-virus software (free trial version) winrar uefi bios asus ez diy

- asus crashfree bios 3

- asus ez flash 3

- asus uefi bios ez mode bios 128 mb flash rom, uefi ami bios gerenciamento wol by pme, pxe acessórios cables

- 2 x sata 6gb/s cables miscellaneous

- 1 x i/o shield

- 1 x m.2 anchor installation media

- 1 x support dvd documentation

- 1 x user guide sistema operacional windows® 11 64-bit, windows® 10 64-bit formato matx form factor 9.2 inch x 8.0 inch ( 23.4 cm x 20.3 cm )

Conteúdo da embalagem:

- Placa-Mãe Asus H610m-d D4 Intel mATX DDR4 RGB - 90MB1a00-m0eay0

Garantia do Fornecedor

3 meses
